DN | PN | ØD | ØK | Ød | C | f | ØLxn | L | l1 |
50 | 10/16 | 165 | 125 | 99 | 19 | 3 | 19×4 | 105 | 75 |
65 | 10/16 | 185 | 145 | 118 | 19 | 3 | 19×4 | 105 | 75 |
80 | 10/16 | 200 | 160 | 132 | 19 | 3 | 19×8 | 110 | 75 |
100 | 10/16 | 220 | 180 | 156 | 19 | 3 | 19×8 | 120 | 75 |
125 | 10/16 | 250 | 210 | 184 | 19 | 3 | 19×8 | 135 | 75 |
150 | 10/16 | 285 | 240 | 211 | 19 | 3 | 23×8 | 135 | 75 |
200 | 10 | 340 | 295 | 266 | 20 | 3 | 23×8 | 135 | 75 |
200 | 16 | 340 | 295 | 266 | 20 | 3 | 23×12 | 135 | 75 |
250 | 10 | 395 | 350 | 319 | 22 | 3 | 23×12 | 140 | 75 |
250 | 16 | 405 | 355 | 319 | 22 | 3 | 28×12 | 140 | 75 |
300 | 10 | 445 | 400 | 370 | 25 | 4 | 23×12 | 135 | 75 |
300 | 16 | 460 | 410 | 370 | 25 | 4 | 28×12 | 135 | 75 |
350 | 10 | 505 | 460 | 429 | 25 | 4 | 23×16 | 150 | 85 |
350 | 16 | 520 | 470 | 429 | 27 | 4 | 28×16 | 150 | 85 |
400 | 10 | 565 | 515 | 480 | 25 | 4 | 28×16 | 150 | 100 |
400 | 16 | 580 | 525 | 480 | 28 | 4 | 31×16 | 150 | 100 |
500 | 10 | 670 | 620 | 582 | 27 | 4 | 28×20 | 165 | 100 |
500 | 16 | 715 | 650 | 609 | 32 | 4 | 34×20 | 165 | 100 |
600 | 10 | 780 | 725 | 682 | 30 | 5 | 31×20 | 165 | 100 |
600 | 16 | 840 | 770 | 720 | 36 | 5 | 37×20 | 165 | 100 |
700 | 10 | 895 | 840 | 794 | 33 | 5 | 31×24 | 165 | 100 |
700 | 16 | 910 | 840 | 794 | 40 | 5 | 37×24 | 165 | 100 |
800 | 10 | 1015 | 950 | 901 | 35 | 5 | 34×24 | 165 | 100 |
800 | 16 | 1025 | 950 | 901 | 43 | 5 | 41×24 | 165 | 100 |
900 | 10 | 1115 | 1050 | 1001 | 38 | 5 | 34×28 | 180 | 115 |
900 | 16 | 1125 | 1050 | 1001 | 47 | 5 | 41×28 | 180 | 115 |
1000 | 10 | 1230 | 1160 | 1112 | 40 | 5 | 37×28 | 180 | 115 |
1000 | 16 | 1255 | 1170 | 1112 | 40 | 5 | 44×28 | 180 | 115 |
